SD8364E
• 1080p Full HD SONY CMOS Sensor
• 30 fps @ 1080p Full HD; 60 fps @ 720p HD
• 30x Zoom Lens
• Removable IR-cut Filter for Day & Night Function
• 360° Continuous Pan and 220° Tilt
• Real-time H.264, MPEG-4 and MJPEG Compression (Triple Codec)
• WDR Pro for Unparalleled Visibility in High Contrast Environments
• Weather-proof IP67-rated and NEMA4X Housing
• -40°C ~ 55°C Wide Temperature Range for Extreme Weather Conditions
• Audio Detection for Instant Alerts
• Auto Tracking for Moving Objects
• Built-in 802.3at Compliant PoE Plus
• 3D Privacy Masks for Additional Protection
• Built-in SD/SDHC/SDXC Card Slot for On-board Storage
• Defog
VIVOTEK SD8364E Footage
VIVOTEK SD8364E is part of the SUPREME series product line offering 1080p Full HD resolution with superb image quality. Adopting a 30x optical zoom lens, the SD8364E is able to capture details at top-notch quality. The IP67- and NEMA 4X-rated housing protects the camera body against rain, dust and corrosion within a wide temperature range between -40°C to 55°C. This feature ensures operation under extreme weather conditions and hazardous environments. It is especially suitable for monitoring wide open indoor/outdoor spaces such as airports, highways and parking lots where high-level reliability and precision are always required.
The SD8364E supports high-performance H.264/MPEG-4/MJPEG compression technology and offers extra smooth video quality with resolution up to 30 fps @ 1080p. Boasting WDR Pro technology, the SD8364E can also cope with challenging lighting conditions and generate image quality close to the capabilities of the human eye. With a sophisticated pan/tilt mechanism, the camera provides fast, precise movement with continuous 360-degree pan and 220-degree tilt. Users can also easily control the lens position via a mouse or a joystick to track the object of interest and set up to 256 preset positions. With the built-in auto tracking feature, the SD8364E provides instantaneous reaction to suspicious moving objects in wide area locations before operators are aware of activity.
As with all VIVOTEK true day/night cameras, the SD8364E features a removable IR-cut filter, maintaining clear images 24 hours a day. With Audio Detection, by recognizing increases or decreases in sound volume, an additional layer of intrusion detection is ensured. With other advanced features such as SD/SDHC/SDXC card slot, 802.3at compliant PoE Plus and 60 fps high quality video, the SD8364E is the best choice for the most demanding outdoor surveillance applications.
Datasheets | Download |
CPU | Multimedia SoC (System-on-Chip) |
Flash | 128 MB |
RAM | 256 MB |
Image sensor | 1/2.8" Progressive CMOS |
Maximum Resolution | 1920x1080 (2MP) |
Lens Type | 30x optical zoom, auto focus |
Focal Length | f = 4.3 ~ 129 mm (30x zoom) |
Aperture | F1.6 ~ F4.7 |
Auto-iris | DC-iris |
Field of View | 2.3° ~ 64° (horizontal) 1.3° ~ 36° (vertical) 2.6° ~ 73° (diagonal) |
Shutter Time | 1/1 sec. to 1/10,000 sec. |
WDR Technology | WDR Pro |
Day & Night | Removable IR-cut filter for day & night function |
Minimum Illumination | 0.5 Lux @ F1.6, 30 IRE (Color), 1/30s 0.03 Lux @ F1.6, 30 IRE (B/W), 1/30s 0.14 Lux @ F1.6, 50 IRE (Color), 1/5s 0.01 Lux @ F1.6, 50 IRE ( B/W ), 1/5s |
Pan speed | 0.05° ~ 450° / sec. |
Pan range | 360° endless |
Tilt speed | 0.05° ~ 450° / sec. |
Tilt range | 220° ( -110° ~ +110° ) |
Preset Locations | 256 preset locations, 40 presets per tour |
Pan / Tilt / Zoom | 48x digital zoom (4x on IE plug-in, 12x built-in) Auto pan mode Auto patrol mode |
On-board Storage | SD/SDHC/SDXC card slot |
Compression | H.264, MJPEG & MPEG-4 |
Maximum Frame Rate | H.264: 30 fps @ 1920x1080, 60 fps @ 1280x720 MPEG-4: 30 fps @ 1920x1080, 60 fps @ 1280x720 MJPEG: 30 fps @ 1920x1080, 60 fps @ 1280x720 (Up to 30/60 fps in WDR mode) |
Maximum Streams | 4 simultaneous streams |
S/N Ratio | Above 50 dB |
Dynamic Range | Above 90 dB |
Video Streaming | Adjustable resolution, quality and bit rate Zoom enhancement for better image quality under limited bandwidth |
Image Settings | Adjustable image size, quality and bit rate Time stamp, text overlay, flip & mirror Configurable brightness, contrast, saturation, sharpness, white balance, exposure control, gain, backlight compensation, privacy masks (Up to 24) Scheduled profile settings Defog |
Audio Capability | Audio input / Audio output (Full duplex) |
Compression | AAC G.711 G.726 |
Interface | External microphone input External line output |
Users | Live viewing for up to 10 clients |
Protocols | IPv4, IPv6, TCP/IP, HTTP, HTTPS, UPnP, RTSP/RTP/RTCP, IGMP, SMTP, FTP, DHCP, NTP, DNS, DDNS, PPPoE, CoS, QoS, SNMP, 802.1X |
Interface | 10Base-T / 100BaseTX Ethernet (RJ-45) * It is highly recommended to use standard Cat. 5e & Cat. 6 cables which are compliant with the 3P/ETL standard. |
ONVIF | Supported, specification available at www.onvif.org |
Video Motion Detection | Triple-window video motion detection |
Auto-Tracking | Auto-tracking on moving object |
Alarm Triggers | Video motion detection, manual trigger, periodical trigger, system boot, recording notification, camera tampering detection, audio detection |
Alarm Events | Event notification using digital output, HTTP, SMTP, FTP and NAS server File upload via HTTP, SMTP, FTP and NAS server |
Connectors | RJ-45 cable connector for Network/PoE connection Audio input Audio output AC 24V power input Digital input*4 Digital output*2 RS-485 for PTZ control (PelcoD protocol, Baud rate 2400) |
LED Indicator | System power and status indicator |
Power input | PoE plus (IEEE 802.3at compliant) High Power PoE AC 24V |
Power consumption | PoE plus: Max. 19W AC 24V: Max. 48W (heater on) Max. 19W (heater off) High Power PoE: Max. 48W (heater on) Max. 19W (heater off) |
Dimensions | Ø: 205 mm x 321 mm |
Weight | Net: 3660 g |
Casing | Weather-proof IP67- and NEMA 4X-rated metal housing Built-in electrical dehumidifier device (SD8364E-M) |
Safety Certifications | CE, C-Tick, FCC Class A, NEMA 4X, VCCI |
Operating Temperature | -5°C ~ 55°C (PoE Plus) -40°C ~ 55°C (AC 24V / High Power PoE) |
Warranty | 36 Months |
System Requirements | |
Operating System | Microsoft Windows 7/Vista/XP/2000 |
Browser | Mozilla Firefox 7~10 (Streaming only) Internet Explorer 9.x or 10.x |
Other Players | VLC: 1.1.11 or above QuickTime: 7 or above |
Product Internal View
Product Outer View
